BARONSHIRE B16-1S VALVE.

The Baronshire B16-1s is designed specifically for Powder Handling and Food Mixing duties and is available in sizes 100mm to 300mm. The valve is designed for lower pressures, up to 2 bar, with an undercut disc/stem facilitating in low torque output. The valve is used extensively in the Pharmaceutical and Food industries where its additional boltholes enable easy installation to hopper,silos and mixers. Unique body design allows the valves to be used as a wafer pattern valve but also allows butt weld or tri-clamp ends to be bolted direct to the valve body.

Baronshire B16-1s Specification:

Body - 316 Stainless Steel
Disc - 316 Stainless Steel
Top - 316 Stainless Steel
Seat - FDA Approved White Silicon or White EPDM

Features & Benefits:

Bubble Tight Shut Off
One Piece Slimline Profile Disc Stem
Clean In Place
Low Torque
High Flowrate
